Item |
Specification |
STM- 2040B |
STM- 2040T |
STM- 2040BD |
|
Optical System |
Infinite Optical System |
Standard |
Standard |
Standard |
|
Viewing Head |
Seidentopf binocular head, 30° inclined, Interpupillary 48-75mm |
Standard |
|
|
|
Seidentopf trinocular head, 30° inclined, Interpupillary 48-75mm |
|
Standard |
|
|
|
Built-in 3.0MP digital camera with ScopeImage 9.0 Software; Binocular Head, Inclined at 30°, Interpupillary Distance 48-75mm |
|
|
Standard |
|
|
Eyepiece |
Wide Field Eyepiece WF 10×/18mm |
Standard |
Standard |
Standard |
|
Extra Wide Field Eyepiece EW10×/20 with Diopter Adjustment |
Optional |
Optional |
Optional |
|
|
Objective |
Infinite Semi-plan Achromatic Objectives 4×, 10×, 40×, 100× |
Standard |
Standard |
Standard |
|
Infinite Plan Achromatic Objectives 2×, 4×, 10×, 20×, 40×, 60×, 100× |
Optional |
Optional |
Optional |
|
|
Nosepiece |
Backward Quadruple Nosepiece |
Standard |
Standard |
Standard |
|
Backward Quintuple Nosepiece |
Optional |
Optional |
Optional |
|
|
Stage |
Double Layers Mechanical Stage 140mm×140mm/ 75mm×50mm |
Standard |
Standard |
Standard |
|
Left hand operation Double Layers Mechanical Stage 140mm×140mm/ 75mm×50mm |
Optional |
Optional |
Optional |
|
|
Condenser |
Sliding-in Centerable Condenser NA1.25 |
Standard |
Standard |
Standard |
|
Focusing |
Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 20mm |
Standard |
Standard |
Standard |
|
Illumination |
1W S-LED Lamp, Brightness Adjustable |
Standard |
Standard |
Standard |
|
6V/20W Halogen Lamp, Brightness Adjustable |
Optional |
Optional |
Optional |
|
|
Optional accessories |
Phase Contrast Kit |
Optional |
Optional |
Optional |
|
Dark Field Attachment |
Optional |
Optional |
Optional |
|
|
YX-2 Epi-fluorescent Attachment |
Optional |
Optional |
Optional |
|
|
FL-LED Epi-fluorescent Attachment |
Optional |
Optional |
Optional |
|
|
Package |
1pc/carton, 35cm*35.5cm*55.5cm, gross weight: 12kg |
Standard |
Standard |
Standard |
STM-2040 series microscopes are ideal instruments in biological, pathological, histological, bacterial, immune, pharmacological and genetic fields. They can be widely used in medical and sanitary establishments, such as hospitals, clinics, laboratories, medical academies, colleges, universities and related research centers.
|
