Features

Light Path Design: Double Beam

STA-8200 series’ double light path design can prevent circuit fluctuation and stray light to ensure stability of the instrument.

Long Path Light Design:

STA-8200 series’ unique 520 mm long light path design greatly improved resolution and the bandwidth can reach 0.5 nm.

16 mm Optical Base:

STA-8200 series use a rigid 16 mm diecast aluminum base as their optical mount to ensure the stability and reliability.

6 inches LCD Display:

STA-8200 series have a 6 inches LCD display to show results and curves directly on the screen.

Powerful Software Functions:

Multi functions like spectrum scanning standard curve, kinetic, multi wavelength scanning,

DNA/Protein testing can be operated directly on the PC.

Multi Function on Spectrophotometer:

Multi functions operated directly on the spectrophotometer and display the test results’ curve and data: wavelength scanning, standard curve, kinetics, multi wavelength scanning,

DNA/Protein test.

Perfect Calibration System:

All baseline, wavelength, dark current can be calibrated automatically to keep good running conditions.

Data Output:

STA-8200 series are equipped with USB port to connect with a PC; the software comes standard with instrument.

Specifications

Model	STA-8200F	STA-8200V	STA-8200
Optical System	Double Beam(1200 Lines/mm Grating)	Double Beam(1200 Lines/mm Grang)	Double Beam(1200 Lines/mm Grating)
Wavelength Range	190-1100nm	190-1100nm	190-1100nm
Bandwidth	1.8nm	0.5,1.0,2.0,4.0nm	1.0nm
Wavelength Accuracy	± 0.3nm	± 0.3nm	± 0.3nm
Wavelength Repeatability	0.2nm	0.2nm	0.2nm
Photometric Accuracy	± 0.3%T	± 0.3%T	0.3%T
Photometric Repeatability	0.2%T	0.2%T	0.2%T
Photometric Range	-0.3-3A, 0-200%T, 0-9999C	-0.3-3A, 0-200%T, 0-9999C	-0.3-3A, 0-200%T, 0-9999C
Stability	± 0.001A/h @ 500nm	± 0.001A/h @ 500nm	± 0.001A/h @ 500nm
Baseline Flatness	± 0.001A	± 0.001A	±0.001A
Noise	± 0.001A	± 0.001A	±0.0001A
Stray Light	≤ 0.05%T @ 220nm, 360nm	≤ 0.05%T @ 220nm, 360nm	≤ 0.05%T @ 220nm, 360nm
Data Output Port	USB	USB	USB
Printer Port	Parallel Port	Parallel Port	USB Port
Display	320*240 Dots LCD	320*240 Dots LCD	320*240 Dots LCD
Lamps	D2 Lamp & W Lamp	D2 Lamp & W Lamp	D2 Lamp & W Lamp
Detector	Silicon Photodiode	Silicon Photodiode	Silicon Photodiode
Power Requirements	AC 220V/50Hz	AC 220V/50Hz	AC 220V/50Hz
Dimension	625430206mm	625430206mm	625430206mm
Weight	32kg	32kg	32kg

Standard Accessories

Sr#	Description	Quantity	Unit
1	Spectrophotometer	1	Set
2	1 cm Glass cuvette	4	Set
3	Power cord	1	Set
4	User’s Manual	1	Set
5	1 cm quartz cuvette	2	Set
6	Dust cover	1	Set

Accessories

Item	Model No	Description	Unit
Cell Holder	100101	10mm single cell holder	Pcs
	100102	10mm 4-hole cell holder	Pcs
	100103	50mm 4-hole cell holder	Pcs
	100104	100mm 4-hole cell holder	Pcs
	100105	10mm 8-hole auto cell holder	Pcs
	100106	10mm single hole water jacketed ambiknt cell holder	Pcs
	100107	Adjustable cell holder for micro cuvettes	Pcs
	100108	Transparent film holder	Pcs
	100109	Test tube holder	Pcs
Control Units	200101	Peltier System	Pcs
	200102	Sipper system	Pcs
	200103	Peltier/sipper system	Pcs
	200104	Micro printer	Pcs
Lamps	300101	W lamp 12V, 20W (Phillips)	Pcs

Literature

STA-8200 Series(1).pdf
