Model

STC5H-500C

STC5H-600C

STC5H-2000C

Shutter Mode

Global

Rolling

Rolling

Sensor Model

IMX264LQR-C

IMX178LQJ-C

IMX183CQJ-J

Sensor Type

CMOS 2/3" Color

CMOS 1/1.8" Color

CMOS 1" Color

Pixel Size

3.45x3.45(μm)

2.4x2.4(μm)

2.4x2.4(μm)

Resolution

2448(H)x2048(V)

3072(H)x2048(V)

5472(H)x3648(V)

Frame Rate

35fps(2448x2048)

35fps(1224x1024 2x2bin)

88fps(1224x1024)

41fps(3072x2048)

41fps(1536x1024 2x2bin)

15fps(5472x3648)

53fps(2736x1824 2x2bin)

67fps(1824x1216 3x3bin)

Color Temperature

2000-15000K

Picture Format

JPG/PNG/TIFF

Interface

Data Interface: USB3.0, Optical Interface: Standard C-Mount

Multiple Cameras

Supports 4 Cameras Simultaneously in SDK

PC Software

Capture V2.0

Operating System

Windows is supported and Linux/Mac is under development

PC Configuration

CPU: Intel Core i5 or better(Quad or more Core); RAM: 8G or more, OS: Windows 7/8/10 64bit

Size & Weight

Size: 68x68x46mm Weight: 330g
