Stalwart

Real time display of collector temperature & vacuum level
Automatic control of freeze-drying process, program can be set by users
Can be switched to manual operation mode at any time needed, to realize entire control of freeze-drying process.
Record vacuum rate, cold trap temperature, material temperature, shelf temperature, USB port for data download.
Alarms for temperature and vacuum level, guarantee the safety and stability of operation.
Digital password protection

The cold trap cavity and material shelf are made of 304L stainless steel, corrosion-resistant and easy to clean.
Material pre-freezing function.
Automatic defrost for easy use.
The cold trap drying chamber is made in aviation-class plexiglass transparent material, which can observe material status clearly.
World-class compressor, optimized cooling efficiency, fast cooling, lower power consumption & environment friendly.
Two temperature ranges available. -60° C models for aqueous samples, and -85° C models for low eutectic temperatures materials.
Various drying accessories to process flasks, vials, ampoules or bulk.

	Model	STFD 25B	STFD 25BH	STFD 25S
Feature	Drying Chamber type	Standard type	Manifold type	Stoppering type
	Ice Condenser capacity	6Kg/24h
	Final condenser temperature	≤-60°C
	Effective shelf area	0.25m2	12x250ml flasks	0.19m2
Shelf	Shelf layers	4	/	3
	Shelf tray dimension	Diameter Φ300 mm
	Height between shelves	70mm	/	70mm
	Shelf heater	Optional	/	Optional
Refrigerant system	Refrigerant gas	Mixed CFC free, HCFC-free
	Number of compressors	1
	Cold trap cooling rate	20℃ to -40℃ ≤30min (no load)
Control	Controller	5 Inch colour touch screen controller with operation system
	Freeze-drying Process	User Programable optional	/	User Programable optional
	Data Storage	Yes
	USB port	Yes
	RS232 port	Yes
	Auto defrost	Yes
Power	Voltage	220v50hz,220v60hz,110v60hz
	Current	Main unit 5A
	Total power	2150W	2300W	2150W
Vacuum pump	Vacuum pump	Yes
	Vacuum degree	≤5Pa (no load)
	Vacuum pumping rate	from standard atmospheric pressure to 10Pa≤10min (no load)
	Vacuum rate	2L/s
Main unit	Vacuum leakage	3x10
	Material	304
	Condenser trap material	SUS304
	Sensor type	PT100
	Material sensor	±4
	External dimensions (L×W×H)	640540845mm
	Weight	127kg
