Stalwart

SMC-24

High-speed Centrifuge

SMC-24 high-speed centrifuge is widely used in life science, biology, molecular biology, physical and chemical

analysis and other fields, for the separation of cells, proteins, virus samples, etc. The maximum speed can

reach 15000rpm.

Quantity :

Add to Inquiry Basket

Features
Specifications
Literature
User Manual

Features

• High-speed and stable operation, the rotor and the motor shaft are matched with high-precision cones, high

concentricity, and low operating noise.

• Both the upper cover and the lower shell adopt high-strength metal protective rings, which have high

structural safety and ensure the safe operation

• of the rotor at high speed.

• The invention patent of the upper cover safety lock ensures the safety during operation. It automatically

pops up after the operation is completed, and

• has one-key open cover function.

• Adopting the three-dimensional air inlet circulation cooling method, the cooling effect is good, and the

temperature rise of the rotor is low.

• Powerful DC brushless motor, maintenance-free, fast drive, ultra-quiet operation, low noise level.

• After the centrifugation is finished, the sound prompts and the cover will automatically opened, which is

convenient for the sample to cool down; the

• brake is soft to protect the special sensitive samples.

• The speed up/down speed is adjustable, suitable for different experimental requirements.

• It adopts 4.3-inch color LCD screen, which can display the speed, centrifugal force and time at the same

time.

• The buzzer prompts after the operation is completed, with the function of displaying the running status and

prompting the error code.

• With PROG key, you can call the built-in 10 groups of programs with one key, which is convenient and

quick to use.

• Equipped with a momentary centrifugal button, which can be centrifuged quickly to meet more

experimental needs.

• High-strength aluminum alloy rotor has no service life limit and can be sterilized by high temperature and

high pressure.

• One machine for multiple purposes, suitable for 0.2, 0.5, 1.5, 2.0, 5.0ml centrifuge tubes and PCR

centrifuge tubes, four rotors are available.

Specifications

Model	SMC-24
Speed range	500-15000rpm (increment: 100rpm)
Time range	1s-99min59s (can be centrifuged instantly)
Speed up down time range	25 or 45s (to protect special sensitive samples from resuspension)
Rotor capacity	0.2ml/0.5ml/1.5ml/2mlx24; 0.2ml×8 strip×4; 0.5mlx36; 5ml×18;
Max. RCF	21400xg
Temp.control accuracy (at 4°C)	±2℃
Time from R. T. to 4°C	≤8min
Working noise	≤62 dB
Safety	High-strength metal protective ring, safety door lock, overspeed, overtemperature, status diagnosis
Other functions	Speed/acceleration display function, instantaneous centrifugal function, running progress display, sound prompt function
Voltage	AC 220V 50Hz
Max. power	500W
Fuse	250V ,15A, φ5×20
Dimensions (W x D x H)	W.238XD.335XH.208mm
Net weight	13kg

Literature

SMC-24(1).pdf

User Manual

SMC-24 Manual.pdf
